Save $354
1U 19" Rackmount Monitor
1920 × 1200 Resolution
Special Price
from $3,195.00
Regular Price
from $3,549.00
10% OFF
Part
RM-111-X19-Cat5-08
Product Information
- Standard Video Input - VGA + DVI-D + HDMI
- Includes 6' IEC power cord, 6' USB/DVI video cable or USB/VGA or USB HDMI video cable
- Video Option - HDMI w/Speaker & SDI Input
- 104 Key Notebook Keyboard, Touchpad or Trackball Mouse
- Mounting Range - 18.1" to 29.5"
| Product Specification | Product Specification
|
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Product Specification
| Console Port | |
|---|---|
| Video input | VGA + HDMI 1.4 |
| Keyboard and Mouse | USB |
| HDMI console - 6ft cable : or VGA console - 6ft cable : | Drawer end : DB-15 + USB Type A x 2 server end: DB-15 + USB Type A x 2 |
| Drawer end : HDMI + USB Type A x 2 server end: HDMI + USB type A x 2 |
|
| Video Option | ||
|---|---|---|
| SDI | 3G HD SD-SDI | |
| LCD Panel | |
|---|---|
| Panel Size (diagonal) | 18" |
| Native resolution | 1920 x 1200 |
| Brightness(cd/m²) | 300 |
| Contrast ratio (typ.) | 1000:1 |
| Max Color | 16.7 M, 8-bit |
| Contrast angle(L/R/U/D) | 89/89/89/89 |
| Responsive time(ms) | 9 |
| Dot pitch (mm) | 0.202 |
| Display area (mm) | 387.76H x 242.35V |
| Surface treatment | Anti- glare. Hard-coating |
| Surface hardness | 3H |
| Backlight type | LED |
| MTBF(hrs) | 15,000 |
| Power | ||
|---|---|---|
| Input | Input Auto-sensing 100 to 240 VAC, 50/60Hz | |
| Consumption (console / KVM) |
Screen on | Max. 23W / Max. 48W |
| Power saving mode | Max. 2W / Max. 34W | |
| Power button off | Max. 1W / Nil | |
| Physical | ||
|---|---|---|
| Product (W x D X H) |
Single console | 442 x 470 x 44mm 17.4 x 18.5 x 1.73 inch |
| Console W/ KVM | 442 x 590 x 44mm 17.4 x 23.2 x 1.73 |
|
| Packing (W x D X H) |
Single console/ Console W/ KVM |
590 x 808 x 140mm 23.2 x 31.8 x 5.5 inch |
| Net weight |
Single console | 12 kg / 26.4 lb |
| Console W/ KVM | 13 kg / 28.6 lb | |
| Gross weight |
Single console | 16.6kg / 36.5 lb |
| Console W/ KVM | 19 kg / 41.8 lb | |
| Environment | |
|---|---|
| Operating temp. | 0 to 55°C degree |
| Strorage temp | -20 to 60°C degree |
| Operating humidity | 20~90%, non-condensing |
| Storage humidity | 5 ~90%, non-condensing |
| Operating alttiude | 16,000 ft |
| Non-operating attude | 40,000 ft |
| Shock | 10G acceleration (11ms duration) |
| Vibration | 10~300Hz .5G RMS randon vibration |
| Mounting Distance | |
|---|---|
| Single console drawer | 470 ~ 700 mm 18.5 ~ 27.6 inch |
| Console W/ KVM drawer |
470 ~ 800mm |
| Compliance | |
|---|---|
| EMC | FCC & CE certifiled |
| Safety | CE/ LVD certified |
| Environment | RoHS2 & REACH compliant |
