6U 17" 1920 X 1080 Rackmount LCD Panel, VGA + HDMI Input (RMP-161-F17)
Special Price
from $913.00
Regular Price
from $1,132.50
- Standard Video Input - VGA + HDMI Video
- Video Option - Add DVI-D, DP, BNC
- Video Option - Add 3G/HD/SD-SDI to above video input
- Touchscreen Option - Resistive Touch Screen
- TAA Compliant
- (Select RMP-161-17A or RMP-161-17K for Capacitive multi-touch)
More Information
| Product Specification |
Product Specification
| LCD Panel Video Specs |
| Video input |
VGA + DVI-D single link |
| Video Option |
| Digital / Analog |
HDMI / SDI / Composite |
HDMI 1.3 / HDCP 1.1
3G / HD / SD-SDI Broadcast Grade Input
S-Video (4-pin) + Composite (BNC)
NTSC & PAL |
| LCD Panel |
| Panel Size (diagonal) |
17.3" |
| Native resolution |
1920 x 1080 |
| Brightness(cd/m²) |
400 |
| Contrast ratio (typ.) |
600:1 |
| Max Color |
16.7 M, 8-bit |
| Contrast angle(L/R/U/D) |
80/80/60/80 |
| Responsive time(ms) |
40 |
| Dot pitch (mm) |
0.1989 |
| Display area (mm) |
381.888H x 214.812V |
| Surface treatment |
Anti- glare. Hard-coating |
| Surface hardness |
3H |
| Backlight type |
LED |
| MTBF(hrs) |
50,000 |
| Power |
| Input |
Input Auto-sensing 100 to 240 VAC, 50/60Hz |
Consumption
(console / K/M) |
Screen on |
Max. 25W |
| Power saving mode |
Max. 4W |
| Power button on |
Max. 1W |
| Physical |
Product
(W x D X H) |
Millimeters |
480 x 48 x 266mm |
| Inches |
17.9 X 1.9 X 10.5 inch |
Packing
(W x D X H) |
Millimeters
Inches |
529 x 124 x 451mm
20.8 x 4.9 x 17.8 inch |
Net
weight |
KGs |
4.5 kg |
| LBS |
9.8 lb |
Gross
weight |
KGs |
6 kg |
| LBS |
13.2 lb |
| Environment |
| Operating temp. |
0 to 55°C degree |
| Strorage temp |
-20 to 60°C degree |
| Operating humidity |
20~90%, non-condensing |
| Storage humidity |
5 ~90%, non-condensing |
| Operating alttiude |
16,000 ft |
| Non-operating attude |
40,000 ft |
| Shock |
10G acceleration (11ms duration) |
| Vibration |
10~300Hz .5G RMS randon vibration |
| Compliance |
| EMC |
FCC & CE certifiled |
| Safety |
CE/ LVD certified |
| Environment |
RoHS2 & REACH compliant |
|
High Resolution Rackmount LCD Panel Features
- 6U 17" 1920 X 1080 Rackmount LCD Panel
- Video Input - VGA + HDMI
- PIP & Picture by Picture viewing efficiency
- VESA & Rackmount Mounting Options
- Green LED Backlit Panel Technology
- Ideal for CCTV security & industrial control
- 2 Year Warranty
Rackmount Display Options - -
- Video: DVI-D, DP, BNC, Speaker + Audio
- Broadcast: 3G / HD / SD-SDI Broadcast Grade Input
- Display: MCS - Multi Display Control (RS232 Controller)
- Locking: MIL Type Connector (DC Power & VGA)
- Tuner: Digital TV Tuner (decodes ATSC Signal)
- Power: 12VDC, 24VDC, 48VDC
- Touchscreen: Resistive only
- Warranty: Extended 3 Year Warranty
Download More Info -
Product Specification
| LCD Panel Video Specs |
| Video input |
VGA + DVI-D single link |
| Video Option |
| Digital / Analog |
HDMI / SDI / Composite |
HDMI 1.3 / HDCP 1.1
3G / HD / SD-SDI Broadcast Grade Input
S-Video (4-pin) + Composite (BNC)
NTSC & PAL |
| LCD Panel |
| Panel Size (diagonal) |
17.3" |
| Native resolution |
1920 x 1080 |
| Brightness(cd/m²) |
400 |
| Contrast ratio (typ.) |
600:1 |
| Max Color |
16.7 M, 8-bit |
| Contrast angle(L/R/U/D) |
80/80/60/80 |
| Responsive time(ms) |
40 |
| Dot pitch (mm) |
0.1989 |
| Display area (mm) |
381.888H x 214.812V |
| Surface treatment |
Anti- glare. Hard-coating |
| Surface hardness |
3H |
| Backlight type |
LED |
| MTBF(hrs) |
50,000 |
| Power |
| Input |
Input Auto-sensing 100 to 240 VAC, 50/60Hz |
Consumption
(console / K/M) |
Screen on |
Max. 25W |
| Power saving mode |
Max. 4W |
| Power button on |
Max. 1W |
| Physical |
Product
(W x D X H) |
Millimeters |
480 x 48 x 266mm |
| Inches |
17.9 X 1.9 X 10.5 inch |
Packing
(W x D X H) |
Millimeters
Inches |
529 x 124 x 451mm
20.8 x 4.9 x 17.8 inch |
Net
weight |
KGs |
4.5 kg |
| LBS |
9.8 lb |
Gross
weight |
KGs |
6 kg |
| LBS |
13.2 lb |
| Environment |
| Operating temp. |
0 to 55°C degree |
| Strorage temp |
-20 to 60°C degree |
| Operating humidity |
20~90%, non-condensing |
| Storage humidity |
5 ~90%, non-condensing |
| Operating alttiude |
16,000 ft |
| Non-operating attude |
40,000 ft |
| Shock |
10G acceleration (11ms duration) |
| Vibration |
10~300Hz .5G RMS randon vibration |
| Compliance |
| EMC |
FCC & CE certifiled |
| Safety |
CE/ LVD certified |
| Environment |
RoHS2 & REACH compliant |
Rackmount Monitor Specifications
Rackmount Monitor User Manual
